ApeosPro C810 / C750 / C650 for Photo

Production printer for photo lab – “ApeosPro for Photo” is the special printer tuned for photo applications.

Overview

Print Speed: Colour / Monochrome 81 / 75 / 65 ppm (Max)
Printing system addressability: 2400 × 2400 dpi
Paper Weight: 52 to 350 gsm
Paper Size: 100 × 148 to 330 × 1300 mm^*1

*1 When feeding paper from Bypass Tray installed directly to the printer, or from Multi Sheet Inserter for Banner Print.
When printing on one side.
2 sided printing is up to 330 × 762 mm.

Features

PRINT QUALITY

ApeosPro for Photo Firmware Fine-tuned for Photography

ApeosPro for Photo has achieved the optimum print quality for photo applications through special image processing that smoothly reproduces skin tone. The high image quality of ApeosPro for Photo

“World’s first” high resolution LED printhead print output

Latest technology to achieve professional quality images and high-definition printing.

World’s first^*1 LED printhead with 2400 dpi resolution
Vibrant colors and smooth gradation thanks to the minute toner particles of the Super EA Eco toner
Crisp reproduction of images with fine lines and tiny text
*1 Dry-type electrophotographic method. According to our research as of March 2021

Maintain print quality with easy adjustment

Use inbuilt standard SIQA^*2 to easily & quickly adjust the print quality.

Simply scan the dedicated charts to automatically calculate the appropriate adjustment values for both Side 1 & 2 Registration, Density Uniformity Adjustment, and Adjust Image Transfer
*2 Simple Image Quality Adjustment

VERSATILITY

The ApeosPro for Photo’s exceptional paper-handling capacity means this system can cater to a diverse range of applications.

Supporting various paper stock to cover the wide range of applications including photo albums, photo prints.
It supports a wide range of paper sizes, from minimum size of 100.0 mm × 148.0 mm to long paper 330.2 mm × 1300.0 mm.
By adjusting the force applied to the paper according to the paper thickness, stable paper feed is performed even with cardstock paper, and high registration accuracy is achieved.
The optimum output conditions for each type of paper, Such as transfer conditions, can be registered (maximum: 100) so that high-quality output can be achieved efficiently simply by selecting the paper type.
Free from volatile solvent for excellent safety and environ mental performance.
By realizing speedy calibration with the scanner built into the printer, it contributes not only to maintaining print quality but also to improving the operating rate of the printer. These functions greatly reduces the load on the photo lab users.

Can creates the variety of high-quality value-added photo products in photo labs

Beautiful post-processing output with in-line finishing options

From printing to post-processing, you can do it all at once.

Beautifully designed full page photo booklets with full bleed trim
High-quality booklet with a square back finish for a flat book spine
Crease^*3 function to create unique accordion fold for promotional materials
Insert oversized A3 size paper as covers
Supports frequently used office functions–Punch, Side Stitch, Saddle Staple, and Single Fold

*3 Up to five creases can be made for mountain fold and valley fold. Folding is performed manually.
* Optional. See page 9 for details on the output options and postprocessing.
